Pipeline

The pipeline module provides an extension of the Eelbrain MNE-Experiment pipeline for mTRF analysis.

Module Reference

`TRFExperiment`(root, **state)	Pipeline for TRF analysis (see also: `eelbrain.pipeline.Pipeline`)
`FilePredictor`([resample, columns, sampling])	Predictor stored in files corresponding to specific stimuli
`EventPredictor`([value, latency, sel])	Generate an impulse for each event

Setup

Predictors

Predictors are added to the experiment as files in the {root}/derivatives/predictors directory. Filenames should follow this pattern: {stimulus}~{key}[-{variant}].pickle.

stimulus referes to an arbitrary name for the stimulus represented by this file (see TRFExperiment.stim_var).

key is the key used for defining this predictor in TRFExperiment.predictors.

variant is an optional description that allows several predictors using the same entry in TRFExperiment.predictors. That allows, for example, only defining a single gammatone predictor in TRFExperiment.predictors for different variations of the spectrogram (gammatone-1, gammatone-8, gammatone-on-1, etc.).

Predictors are then added to the pipeline in TRFExperiment.predictors. This is a dictionary in which the key is the key mentioned above, and the value is typically a FilePredictor object. For information on how to handle different kinds of predictors see the FilePredictor documentation. For example:

predictors = {
    'gammatone': FilePredictor(resample='bin'),
    'word': FilePredictor(columns=True),
}

Assuming a stimulus called story, this would match the following predictor files:

predictors/story~gammatone-1.pickle: NDVar UTS predictor, which can be invoked with model term gammatone-1 (see Models)

predictors/story~gammatone-8.pickle: as above, but invoked with model term gammatone-8

predictors/story~word.pickle: a Dataset representing one or multiple NUTS predictors (through different columns in the dataset). The specific model term would include a column name, for example, a model term word-surprisal would use the values of the "surprisal" column in the dataset (see FilePredictor).

Warning

When you change the contents of a predictor file, this will not be automatically detected. In order to remove cached results that incorporated the outdated predictor, use TRFExperiment.invalidate().

Models

When referring to mTRF models, models are sets of terms, each term specifying one predictor variable. For information on how to specify terms for different predictors see the FilePredictor documentation. Models can be constructed by combine terms with +, for example:

x="gammatone-1" is a model with a single predictor

x="gammatone-1 + gammatone-on-1" is a model with two predictor

To shorten long models specifications, named sub-models can be specified in TRFExperiment.models. For example, with:

models = {
    "auditory-gammatone": "gammatone-8 + gammatone-on-8",
}

The combined auditory model can then be invoked with auditory. For example, the effect of acoustic onsets in the combined auditory model could be tested with x="auditory @ gammatone-on-8", which would internally expand to x="gammatone-8 + gammatone-on-8 @ gammatone-on-8".

Use TRFExperiment.show_model_terms() to list all terms in a model, e.g.:

>>> alice.show_model_terms("auditory-gammatone")
#   term
------------------
0   gammatone-8
1   gammatone-on-8

Stimuli

In order to load the correct predictors for a model term, the pipeline also needs to know what stimulus was presented in each trial. For this, use the TRFExperiment.stim_var attribute to determine which event column is used as stimulus name. The default is TRFExperiment.stim_var = 'stimulus'. Thus, given the following events:

#    i_start   trigger   T        SOA      subject   stimulus
-------------------------------------------------------------
0    1863      1         3.726    57.618   S01       s1
1    30672     5         61.344   60.898   S01       s2
...

Using the term ‘gammatone’ in a model would find predictor files based on the stimulus column: s1~gammatone.pickle, s2~gammatone.pickle, …

Multiple stimuli per trial

To look up the stimlus in an event column other than the one specified in TRFExperiment.stim_var, simply specify the relevant column in the model term. For example, assume a selective attention task in which two speakers talk simultaneousy. The attended speaker (‘fg’) and the unattended speaker (‘bg’) can each be considered one stimulus. In addition, the acoustic mixture of the two speakers may be considered a third stimulus (‘mix’). Events may look like this:

#    i_start   trigger   T        SOA      subject   fg   bg   mix
------------------------------------------------------------------
0    1863      1         3.726    57.618   S01       s1   s3   s13
1    30672     5         61.344   60.898   S01       s2   s4   s24
...

The default stimulus could be specified in TRFExperiment.stim_var = 'fg'. Other stimuli (or “streams”) could be specified in model terms with ~:

‘gammatone’ would find predictors based on the default fg column: s1~gammatone.pickle, s2~gammatone.pickle, …

‘bg~gammatone’ would find predictors based on the bg column: s3~gammatone.pickle, s4~gammatone.pickle, …

‘mix~gammatone’ would find predictors based on the mix column: s13~gammatone.pickle, s24~gammatone.pickle, …

Comparisons

When referring to model tests, this usually means comparing two different mTRF models. Basic comparisons can be constructed with >, < (one-tailed) and = (two-tailed):

x="gammatone-1 + gammatone-on-1 > gammatone-1" tests whether predictive power improves when adding the gammatone-on-1 predictor to a model already containing the gammatone-1 predictor.

x="gammatone-1 = gammatone-on-1" tests whether the predictive power of gammatone-1 or that of gammatone-on-1 is higher.

To simplify common tests with large models, the following shortcuts exist:

Shortcut	Example	Expansion	Description
`@`	`a + b + c @ a`	`a + b + c > b + c`	Unique contribution of `a` to the left-hand-side model
`+@`	`b + c +@ a`	`a + b + c > b + c`	Effect of adding `a` to the left-hand-side model

Use TRFExperiment.show_model_terms() to list the terms in the two models involved in a comparison:

>>> alice.show_model_terms("auditory-gammatone @ gammatone-8")
x1               x0
-------------------------------
gammatone-8
gammatone-on-8   gammatone-on-8

Batch estimating TRFs

The pipeline computes and caches TRFs whenever they are requested through one of the methods for accessing results. However, it is often more expedient to estimate multiple TRF models before performing an analysis. This can be done by creating a list of TRF jobs, as in the Alice jobs.py example. These TRFs can then be pre-computed by running the following command in a terminal:

$ trf-tools-make-jobs jobs.py

When running this command, TRFs that have already been cached will be skipped automatically, so there is no need to remove previous jobs from jobs.py. For example, when adding new subjects to a dataset, this command can be used to compute all TRFs for the new subjects. The pipeline also performs a cache check for every TRF, so this is a convenient way to re-create all TRFs after, for example, changing a preprocessing parameter.
